| Datasheet | R3KL1-G2 | R3K6L1-G2 | R4KL1-G2 | R4K6L1-G2 | R5KL1-G2 | R6KL1-G2 | R8KL1-G2 |
| AC output | |||||||
| Rated power(kW) | 3 | 3.6 | 4 | 4.6 | 5 | 6 | 8 |
| Max. output current(A) | 13 | 16 | 17.4 | 20 | 21.7 | 26 | 35 |
| Nominal voltage range(V) | 230 /176-270 | ||||||
| Frequency(Hz) | 50/60 | ||||||
| Power factor | 1(0.8 lagging-0.8 leading) | ||||||
| THDi | <3% | ||||||
| AC output topology | L+N+PE | ||||||
| DC input | |||||||
| Max. input power(kW) | 4.6 | 4.6 | 6 | 6 | 7 | 7 | 12 |
| Start-up voltage(v) | 120 | 125 | |||||
| Max. PV voltage(V) | 550 | ||||||
| MPPT range/nominal(V) | 125-500/360 | ||||||
| Max. input current(A) | 14/14 | 37/18.5 | |||||
| MPPT tracker/strings | 2/1 | 3/2+1 | |||||
| Battery | |||||||
| Battery voltage range(V) | 40-58 | ||||||
| Max. charging voltage(V) | 58 | ||||||
| Charge/discharge current(A) | 95/62.2 | 95/75 | 95/83.3 | 95/95.8 | 95/104.2 | 95/110 | 160 |
| Communication Interface | CAN | ||||||
| EPS output | |||||||
| Rated power(kW) | 3 | 3.6 | 4 | 4.6 | 5 | 6 | 8 |
| Rated voltage(V) | 230 | ||||||
| Rated current(A) | 13 | 16 | 17.4 | 20 | 21.7 | 26 | 35 |
| Rated frequency(Hz) | 50/60 | ||||||
| Automatic switching time(ms) | <20 | ||||||
| THDu | <2% | ||||||
| Overload capacity | 110%, 60S/120%, 30S/150%, 10S | ||||||
| General data | |||||||
| Battery charge/discharge efficiency | 95% | ||||||
| DC max. efficiency | 97.6% | ||||||
| Europe efficiency | 97% | ||||||
| MPPT efficiency | 99.9% | ||||||
| Ingress protection | IP65 | ||||||
| Noise emission(db) | <35 | ||||||
| Operation temperature | -25°C ~60°C | ||||||
| Cooling | Natural | ||||||
| Relative humidity | 0-95%(non-condensing) | ||||||
| Altitude | 2000m(>2000 derating) | ||||||
| Dimensions W*D*H(mm) | 460*495*390 | ||||||
| Weight(kg) | 18 | 20 | |||||
| Inverter topology | transformer less | ||||||
| Self-consumption(W) | <3 | ||||||
| Display and communication | |||||||
| Display | / | ||||||
| Interface:RS485/Wifi/4G/CAN/DRM | Yes/Opt/Opt/Yes/Yes | ||||||
| PV power | <4.6kW | <4.6kW | <6kW | <6kW | <7kW | <7kW | <12kW |
| PV voltage | 125-500V | 125-500V | 125-500V | 125-500V | 125-500V | 125-500V | 125-500V |
| Load power | ≤3kW | ≤3.6kW | ≤4kW | ≤4.6kW | ≤5kW | ≤6kW | ≤8kW |
| Load voltage | 230V | 230V | 230V | 230V | 230V | 230V | 230V |
| Reserve power requirement | 5kWh(1.6h Reserve ) 5kWh(1.38h Reserve) 5kWh(1.25h Reserve) 5kWh(1.08h Reserve) 5kWh(1h Reserve) 5kWh(0.83h Reserve) | ||||||
Mini hybrid solar inverter with Mppt charge controller R3KL1-G2 3Kw
- Support multi-machine parallel connection;
- Compatible with lead-acid or lithium-ion batteries or other battery access;
- Fashion appearance, light weight, smart operation;
- Natural cooling, low noise;
- IP65 , wall mounted design, saving space;
- Compatible anti counter flow function ;
- Battery reverse connect protection;
- Intelligent energy management system for home;
- Power dispatching and demand side response management mode;
- Distributed virtual power station management mode;
FAQ
Q1. Can I get a XXX sample order for test?
A.Yes, we welcome sample order to test and check before bulk order.
Q2. What is the lead time for different products?
A.Standard in stock products 5-7 days, bulk order time needs 3-5 weeks, customized order needs 35 days.
Q3. Do you have any MOQ limit?
A.Yes, we have MOQ for standard production. 1 pc for sample to test is support.
Q4. How do you ship the sample or the bulk order?
A.We usually ship via DHL, UPS, FedEx or Express. It usually takes within a week to arrive. Bulk order is usually shipped by sea.
Q5. How to proceed with the order?
1st Understand specific product requirements and application scenarios
ï‚·2nd Propose solutions and provide quotations
ï‚·3rd Finalize the plan, sample order, deposit
ï‚·4th Order production, delivery of the balance, arrange delivery
Q6. Is it OK to do OEM/ODM for my own logo?
A. Yes. Please share to us with your logo after the order confirmed.
Q7. How about the warranty condition of inverter/UPS?
A. All of industrial or commercial inverter/UPS with 2 year warranty.
Q8. How about cycles life and warranty of the lithium batteries?
A. All of batteries are 2000 cycles lifespan under 80% DOD or 2 years warranty.
Q9. How to choose a right power system?
A. We will recommend you a suitable one in accordance with your requirements and actual applications. To invest a reliable system will cost you less in the long run and bring you wonderful experience.
Q10. Do you provide mounting structures and cables for installations?
A. Yes, we provide all accessories with product including nuts/bolts for the optional guiding, so you can even do it installations yourself.
About Baykee
Aerospace Baykee (Guangdong) Technology Co., Ltd. Relying on the technical benefits of aerospace and the advantages of highly educated personnel in civil industry, focusing on the dual-use field of power technology,
specializing in R & D, production and sales of industrial power supplies, customized power supplies, etc., has formed network energy, renewable energy, emergency power supply system, industrial special power supply, power quality management five business segments. The company has advanced technology of UPS/EPS emergency power supply, modular data center, solar PV inverter, charging pile, energy storage equipment, intelligent power distribution and other homologous products.
At present, the company focuses on emerging industries such as smart city & big data, smart energy, smart transportation, pv energy storage system, and has formed a comprehensive solution such as IDC data center, communication power system, optical storage and charging integrated smart energy system, and intelligent power supply system for rail transit
Baykee Mission & Attitude
Relying on the technical advantages of aerospace and the advantages of the military and civil industry compound highly educated talents, focusing on the “high, fine and advanced” field, to become a leading power quality service provider.
Cooperative, trustworthy and professional:
Aerospace Baykee adheres to the multi-dimensional cooperation strategy, provides customers with personalized and all-round pre-sales technical guidance and the most reliable after-sales guarantee, and provides power for energy development with solid professional background.
Baykee Factory
1. Independent factory
Founded in 2007, the company adheres to the strategy of innovation-driven development, adheres to the concept of “high-end service, excellence”, and adheres to the road of independent brand development. In Foshan has headquarters R & D production base 20000 square meters.
2. More than ten mature production lines
It has more than 350 professional manufacturing plants and more than ten professional production lines.
3. Strong independent research and development team, software and hardware independent research and development
The company has set up a provincial enterprise technology center and a provincial engineering center, and built a CNAS laboratory. Baykee has more than 80 scientific and technological personnel. In the power related fields to create outstanding performance, has launched UPS uninterrupted power, photovoltaic solar inverter, industrial energy storage system, home energy storage system, outdoor energy storage system and other more than 10 high-end power products with industry leading advantages.
4. Timely delivery
The company delivers 130,000 sets of products per month
Quality Assurance
The company has passed ISO9001 quality management system certification, CE certification, IEC certification, MSDS, UN38.3 energy conservation certification, TLC certification, undertook the Guangzhou Tower, Guangdong-Hong Kong-Macao Bridge, Olympic venues, Pakistan Orange Line subway, Nigeria National Railway, Costa Rica National Stadium (ESTADIO NACIONAL DE) COSTA RICA), Iraq Hospital, Hong Kong Queen Mary Hospital, etc.
